LEDJ Slimline 12Q5 RGBW Batten (White Housing)

Housing 12 x 5W quad-colour LEDs, the ultra bright Slimline 12Q5 batten gives smooth colour mixing from rich saturated hues to subtle pastel shades. Just like the other fixtures in the Q5 series, these units have a rugged, metal housing, and a variety of operational modes. The fixtures are also convection cooled for silent operation.

The Slimline 12Q5 batten is the next generation of our ever-popular Q5 series, all of which are compatible, giving you the option to link together a variety of units from the 12Q5, 7Q5 and 5Q5 ranges. These can then be easily operated via the optional IR remote creating a fully synchronised lightshow.

12 x 5W quad-colour LEDs (RGBW)

Beam angle: 25° (field angle: 40°)

400Hz refresh rate

DMX channels: 2/3/4 or 7 selectable

Static colour, colour change, colour fade, auto run, sound active and master/slave modes

0-100% dimming and variable strobe

Bracket allows for multiple rigging or floor standing applications

4 push button menu with LCD display

IEC in/out sockets

3-Pin XLR in/out sockets

Convection cooled

Optional IR remote (LEDJ90C)

Linkable with the Slimline 5Q5 and 7Q5


• Power consumption: 70W
• Power supply: 100~240V, 50/60Hz
• Fuse: F1A 250V
• Dimensions: 87 x 1018 x 63mm
• Weight: 2.2kg
